Floor Grinding And Polishing Machine
1. Self-driving grinding machine saves labor and realizes easy grinding1. Self-driving grinding machine saves labor and realizes easy grinding
2. Using the internationally renowned brand WEG motor, the S1 working system has a large starting torque, and the motor is maintenance-free and has a long service life
3. The frequency converter adopts the DELTA brand, which can be controlled by V/F curve, vector torque and has a fault warning function.
HTG-680-4A Concrete Floor Polisher
Xingyi enterprise was found in 1999,and specialized in producing floor grinder machines,polishers,grinding pads and floor chemicals.And we have awarded 123 patents for inventions.Helping our clients finished many kinds of floor maintance grinding polishing projects.We are offering Floor Grinder of one of the best quality to the clients. Clients could easily avail from us the truly versatile and highly reliable range of this Floor Grinder at legitimate prices. These are energy efficient and are able to give reliable performance over long period of time. Even a layman could easily install this Floor Grinder without much expertise.
Company advantage
1.We are the one of the biggest system integrates which providing Full-floor polishing products and service in China.
2.Our annual international floor treatment seminar is more and more popular among famous connoisseurs.
3.We have a 34 foreign offices across the global so that we can provide an extremely details and customer support.
4.Not only we are a factory,but also have our own engineering company.Any questions about the machines or projects,we can give you a free technical guidence.
Product Introduction
680-4A self-driving terrazzo, marble, cement and concrete floor grinding wheel polishing machine is a self-driving grinder and one of the most efficient floor grinding equipment produced by Xingyi Company. Adopting a four-head planetary counter-rotating gear structure, the planetary gears rotate in different directions, which reduces the deflection force of the machine, has strong grinding efficiency and stable performance, makes grinding more stable and uniform, and improves grinding efficiency. And it saves time and effort. Compared with the three-head grinder, the four-head grinder has more force on the uneven surface and the work is more stable. This grinding machine has an automatic drive system, 15HP world-class WEG motor, 20HP Delta frequency converter, plus a weight of 425KG, with high grinding pressure and stable performance. If you are looking for a user-friendly and efficient floor repair and removal machine suitable for industrial applications, then there is no doubt that 680-4A is the right choice.
Product advantages
1.Self-propelled concrete stone floor grinder HTG-680-4A is used to grind different kind of floor.variable speed adjust providing you with more versatility and more flatly contrast with others.
2.Internationally well-known brands WEG motors and DELTA inverters have passed CE certification, global joint warranty quality assurance
3.Equipped with aluminum alloy wheels and high-quality bearings (China's first-line brand HRB bearings), firm and durable,
4.Thickened integrated gearbox, excellent heat dissipation, anti-corrosion, patented output shaft double-layer oil seal design, no oil leakage, durable and long service life
Product parameter
Model Name | 680-4A |
Working Width | 680mm |
Voltage | 380V-440V 3 phase |
Motor HP | 11KW WEG motor |
AC Motor driver | 15KW Delta inverter |
Rotating Speed | 350-1680rpm |
Grinding disc | 230mm*4 |
Water tank | 16L |
Weight | 425kg |
■4-head planetary counter-rotating grinding disc
■Integrated control panel, easy to operate
■Stainless steel water tank for dry and wet grinding
■Three-stage weighted iron design
■Power balance device, stable operation
■Timer for easy time management
■PE floating dust cover, strong and durable
Internationally renowned accessories：
✔Brazil WEG Motor
✔DELTA Inverter
✔Sweden SKF Bearing
✔Germany Phoenix contact
✔Germany Schneider Switch button
Customer Demo
FAQ
Q1:How thick does a polished concrete floor need to be?
A1:50 mm
The method used for retrofitting a polished concrete floor is either to (a) cut or sand the existing floor slab to be hardened and polished, or (b) apply a topping slab of polished concrete flooring, at least 50 mm thick, over the existing slab.
Q2: how do you maintain a floor grinder?
A2:
1. Clean the grinder every day after work, especially the dust on dust skirt and grinding plates.
2. Clean the water tank every week to prevent the dust blocks the filter.
3. After finishing each job site, all bolts and grinding plates need to be checked and fasten.
4. If the machine is often used in dry grinding, then the cooling fan of inverter need to be cleared every 20-30days.
5. Replace the gear oil termly. Usually, a new floor grinder needs to replace the gear oil after six months of use. Later, the gear oil needs to be replaced once a year.
6. Ask professional technician to do the machine maintenance and record the content of maintenance.
Hot Tags: Floor Grinding And Polishing Machine,self-propelled concrete grinder, floor grinder machine
