12 Grinding Head Terrazzo Grinding Machine
Model：680-4E
Power：11KW
Advantage：1. The machine has a special balance device to make the grinding more even;
2 Working width 680mm, high working efficiency;
3. Additional weight of 20kg*2 makes grinding easier;
4. The four-head grinding head is equipped with a planetary grinding disc, which provides more powerful power for the grinding head, ensures concrete grinding, and makes the operation smoother;
5. The high-power three-phase voltage can be used in any engineering site.
12 Grinding Head Terrazzo Grinding Machine
The 680-4E is especially suitable for the high precision requirement concrete surface grinding and construction work. The machine has the advantages of time-saving, labor-saving, high efficiency .
Technical parameter
Model Name | 680-4E |
Voltage | 380V-440V 3 phase |
Ampere | 22.9A |
Working width | 680mm |
Grinding disc | 230mm*4 |
Motor Rotating speed | 450-1950rpm |
Motor HP | 11KW/15HP |
Inverter | 15KW/20HP |
Configuration | WEG motor + Delta inverter |
Weight | 500kg |
Extra weight | 20kg x 2 |
Water tank | 15L |
Product Details
Advantages
1. The machine has a special balance device to make the grinding more even;
2 Working width 680mm, high working efficiency;
3. Additional weight of 20kg*2 makes grinding easier;
4. The four-head grinding head is equipped with a planetary grinding disc, which provides more powerful power for the grinding head, ensures concrete grinding, and makes the operation smoother;
5. The high-power three-phase voltage can be used in any engineering site.
6. It uses an All-aluminum alloy gearbox and gear-drive planetary head to reduce noise and improve surface flatness.
Customer Praise
Customer Demo
Related Products
Our Company
Grinding machines are sold to countries and regions
Marble Floor Polishing Machines
FAQ
Q: What is the advantage of planetary rotating design?
A: Planetary design is more powerful and sharp, good at grinding the uneven floor.
Q: Xingyi floor grinding machines are all gear driven?
A: All of our floor grinding machines are gear-driven. The machine with gear-driven is more powerful and effective than belt-driven, for maintenance only need change gear oil.
Q: What are our advantages?
A: Competitive price: We can meet your budget and best-selling business very well.
OEM Accepted: We can produce customized designs.
Good Service: We treat clients as friends and provide problem-solving anytime you need.
Good Quality: We have a strict quality control system. Good reputation in the market.
Fast & Delivery: We have a big discount from the forwarder (Long-term Contract).
Door To Door Service.
